Actisense

Multi-function NMEA2000 Wifi Gateway

SKU: WGX-1-ISO
Available
Add to Cart
Years Warranty
Official Distributor

Description

The WGX-1-ISO is a Multi-function NMEA2000 Gateway, providing Wi-Fi streaming, NMEA data conversion, data logging functionality and includes an ISO (serial / NMEA 0183) port.


The WGX-1 is a powerful routing device allowing advanced routing of data between the NMEA 2000 network, its ISO (serial / NMEA 0183) port and its 3 separate Wi-Fi data servers.


Features:

  •  Bi-directional conversion between NMEA 2000 and NMEA 0183.
  • Wi-Fi streaming via 3 separate data servers.
  • Transfer NMEA 2000 data to connected devices.
  • Can be used to configure and update other Actisense NMEA 2000 devices. (via serial, wi-fi config to be added in future update).

Specifications

  • Input supply voltage : 9-30V DC
  • Nominal voltage : 12V|24V
  • Consumption : 78mA @ 9V DC
  • Connectivity : NMEA2000|NMEA0183|Wifi
  • NMEA2000 inputs : Yes
  • NMEA2000 outputs : Yes
  • NMEA0183 inputs : 1x
  • NMEA0183 outputs : 1x
  • Serial port compatibility : RS422|RS232|RS485|NMEA 0183
  • Baud rate : 4800 to 230400 bps
  • Data transfer/conversion : NMEA2000 to NMEA0183 on Wifi|NMEA2000 to NMEA2000 on Wifi
  • WiFi supported standards : b|g|n
  • Frequency : 2412 - 2484 MHz
  • IP rating : IP68
  • Connector type : Micro-C (NMEA2000)
  • Dimensions : 126x73x24mm
  • Product weight : 112gr
385,25 €
Add to Cart
