X2 Vertical Windlass 24V

The "X" vertical windlasses are suitable for sail and motor boats from 6m to 27m in length.

They have different motorization attributes according to each model.

The standard features that you can meet in every X series windlass are:

• Watertight stainless steel ball bearing in the base (for better functionality and zero maintenance) which is a unique feature in the windlass market.
• The clutch is made by two conical discs connected to the main shaft by two parallel planes on the shaft, in order to avoid using keys and allocate the weight load properly.
• The electric motor and gearbox are connected by a particular coupling that is made by a socket for easier maintenance.
• There is a sensor in the base and a magnet into the gipsy so they can be connected to a chain counter.
• Manual override so that the chain or rope can be recovered manually in case of electric function failure (this feature is not available in the X1 model).

X2 Vertical Windlass Spare Parts

Ordering information: Gypsy chain comes in different sizes.

Mention the size needed (10mm ISO4565 or 10mm DIN766)
