AIS700 - Class B Transceiver

SKU: E70476
Add to Cart


The AIS700 from Raymarine is a Class B Automatic Identification System (AIS) transceiver designed for use with any multifunction navigation display systems.

As a Class B AIS transceiver, the AIS700 not only receives broadcasts from other vessels, it also transmits your own boat’s information too helping you to be seen on other vessels’ systems.


  • Full transmit and receive AIS for enhanced situational awareness and safety
  • Latest SOTDMA technology for longer range and faster performance
  • Built-in antenna splitter simplifies installation with existing VHF radio antenna
  • NMEA2000, NMEA0183, PC (setup & diagnostics) and SeaTalkng compatible
  • Software or hardware switchable Silent Mode for enhanced security when needed.


  • Input supply voltage : 9.6-31.2V DC
  • Nominal voltage : 12V|24V
  • Consumption : 2.5A @ 12V DC
  • Connectivity : NMEA2000|NMEA0183
  • NMEA2000 inputs : Yes
  • NMEA2000 outputs : Yes
  • NMEA0183 inputs : 1x
  • NMEA0183 outputs : 1x
  • Integrated features : Antenna splitter
  • Frequency : 156 - 162.5 MHz
  • Connector type : Micro-C (NMEA2000)|USB|UHF female|N female

Package content:

1x AIS unit

1x GNSS antenna with cable

1x GNSS gasket

1x GNSS pole mount

1x Fixing screws

1x Power/data cable

1x VHF cable

1x Adaptor cable devicenet to stng

1x Documentation
