Actisense
NMEA2000 to NMEA0183 Bi-directional Gateway
SKU: -
Choose Configuration variant
Add to Cart
Years
Warranty
Official
Distributor
Description
Multiple NGW-1 units can be used to multiplex numerous NMEA 0183 devices onto the NMEA 2000 network, using the network as a means of combining and transferring all data from one place to another.
Unit not in production.
Limited stock available.
Replacement unit: NGX-1-ISO
NGW-1: NMEA 2000 to NMEA 0183 Gateway – converts between the old and the new NMEA protocols bi-directionally. It cannot be used to transfer NMEA 2000 messages to the PC; the serial port only understands NMEA 0183.
Specifications
- Input supply voltage : 9.5-35 V DC
- Nominal voltage : 12V|24V
- Consumption : 35mA @ 12 VDC
- Connectivity : NMEA2000|NMEA0183
- NMEA2000 inputs : Yes
- NMEA2000 outputs : Yes
- NMEA0183 inputs : 1x
- NMEA0183 outputs : 1x
- Serial port compatibility : RS422|RS232|RS485|NMEA 0183
- Baud rate : 4800 to 115200 bps
- Data transfer/conversion : NMEA2000 to NMEA0183
- Connector type : Micro-C (NMEA2000)
- Dimensions : 179mm(L)x46mm(W)x28.5mm(H)
- Product weight : 220g
Related products
NGW-1-ISO
The NGW-1-ISO comes with a 1.5m stripped and tinned cable designed to accommodate nearly all NMEA 0183 talkers / listeners and gives you the ability to connect a serial to USB converter cable for connection to a PC USB Port. This device operates at 4800 baud by default.
NGW-1-ISO-AIS
The NGW-1-ISO-AIS is physically identical to the NGW-1-ISO, where the only difference lies in the firmware on the device. The AIS version is configured to have more conversions including AIS enabled and operates at 38400 baud by default.
NGW-1-STNG
The NGW-1-STNG comes with the same 1.5m stripped and tinned cable designed to accommodate nearly all NMEA 0183 talkers / listeners as the NGW-1-ISO. The only difference is the additional STNG (SeaTalk NG) to NMEA 2000 adapter cable provided with the device. The kit is made up of a standard NGW-1-ISO and an STNG-A06045 adapter cable. This cable allows for seamless connectivity between an STNG network and an NMEA 2000 Device Net Connector found on devices such as the NGW-1.
